MATRIX-A6

  • 6 analog inputs/6 analog outputs on rear panel ports
  • 8 digital inputs/8 digital outputs via DANTE32S option card
  • Intuitive GUI via PC
  • Extended remote control unit
MATRIX-A6
  • The MATRIX A6 digital matrix mixer system is dedicated to music, paging, discussion and zone management solutions for audio applications.
  • The MATRIX A6 has 6 analog input and output channels and can be expanded to a 14 x 14 digital matrix through the DANTE32S module
  • The main DSP functions of MATRIX A6 are as follows: gain adjustment, limiter/compressor, ducking function, matrix, noise gate/expander, echo cancellation, parametric EQ, bandpass filter, delay, crossover filter, automatic mixer, etc.
  • Projects using DSP platforms usually require a minimum number of inputs and outputs. This determines the choice of dedicated matrix models. MATRIX A6 supports a variety of peripherals that can be configured through software, and the user-friendly editor makes it easier to set up or modify operations. Real-time reporting of control status and clear graphical indication of all functions. Multiple of I/O options make it ideal for different applications, the system provides remote audio control panel, remote paging microphone and other remote devices MATRIX A6 is easy to engineer, with a fixed architecture for quick and easy operation.
  • MATRIX A6 is easy to engineer, with a fixed architecture for quick and easy operation.

Specification

Connectors
Euroblock 3 x 6-pin, 5mm pitch
CODEC
32-bit, 48K/96K
MIC/ Line Inputs
Active balanced
Gain Settings
+10 to +60dB,1dB steps
Input Impedance
6.8KΩ
Phantom Power(±3V)
+48VDC
THD+N
< 0.03%, typ 20Hz-20KHz, 0dBu A-Weight
Maximum Input
+20dB
Frequency Response
20Hz-20KHz, at 0dBu- 1.5dB A-Weight
Dynamic Range
108dB
Crosstalk
<-88dB, at 20Hz-20KHz, 0dB, CH to CH
Digital Gain Range
0~-48dB Steps=12dB
Outputs
Active balanced
Impedance
200Ω
Maximum Output
+20dBu
Frequency Response
20Hz~20KHz at 0dBu ±1.5dB A-Weight
Dynamic Range
108dB
Crosstalk
<-88dB, at 20Hz-20KHz, 0dB, CH to CH
Indicators
Green(SIG)/Red(CLIP)
Signal
-40dBu Green LED
Overload
+19dBu Max, A-Weighted
DSP
SHARC ADSP-21489,450MHz
Processor
32/64-bit Floating Point
Power Supply
100-240V/50~60Hz
Dimension (W x H x D)
483 x 44 x 256 mm (19.02 " x 1.73" x 10.08 ")
