ZP-15A

  PROFESSIONAL SPEAKER SYSTEM
  • 4000W - 134dB Total System Peak Power
  • DSP Enhanced Bass Response
  • High Efficiency Class D Amplifier
DSP
Bluetooth
ZP-15A



Selection Switch for 4 DSP Presets,  select your Favourite Among live-music-speech-Monitor；

LIVE-for  live  sound  reinforcement   applications(Defaults).

MUSIC-for recording music playback and EDM applications.

SPEECH-for vocal language applications.

MONITOR-for stage monitoring applications.



TWS BT and APP Control  Sound Control APP controls the DSP parameters of the speaker via Bluetooth, Feature:

1. Adjust the frequency, gain, Q factor, filter type and other parameters of EQ;

2. Adjust the input gain, Mute;

3. Save the current preset to the device or locally, and load the preset.

4. Restore factory settings with one click.







High Efficiency Class D Amplifier



Using Analog Devices ADAU DSP,perfectly tuned for each model, audiences will experience absolute clarity and deep, powerful bass response.

ADVANCED TRANSDUCERS
1.Best-in-Class Compression Driver
2.Less distortion and more stable PEN Diaphragm Designs
3.More Consistent Energy Transfer

Professional woofer design for tight, powerful bass
1.Exclusive Woofer Excursion Management
2.Extended Low-Frequency reproduction

Specification

ZP-15A

2-WAY 15 Active Vented Loudspeaker System

B-AMP DSP Processor,1000W continuous RM5 (Class D LF-650W+HF-350W)
4000 Wpeak 2600 WLF +1400 WHF)

LOW
650W
HIGH
350W

LOW
1300W
HIGH
700W

15"(367mm).cone

1"Throat Compression Driver

2.0kHz

134 dB (peak), 131 dB (continuous) (dB-SPL@ 1 m)

50 Hz- 20 kHz (-3dB)

43 Hz- 20 kHz (-10 dB)

90° horizantal x 60° vertical(normal)

LIVE-MUSIC-SPEECH-MONITOR

2xXLR+1/4" (6.35 mm) TRS combo inputs (Line/Mic)
1x3.5 Stereo AUX IN,1x Stereo BT(app controls)
1x XLR mix output (Link)
1x lEC power cable input

Stereo L/R-VOL-Pair-Link Switch APP control)

Volume Control knob. AC Power switch, Line / Mic toggle switch,
DSP Preset Switch
BT Pair and Link Switch

Signal/ Clip Limiter LED. Four DSP Mode LEDs,BT Pair-Link LED, Power Switch LED

Connection
IEC
Voltage
110-120V-,220-240V-,50/60Hz
switchable Fuse
100-120VT10ALAC250Var220-240VT5AL AC250V
Consumption
800 W

Electronic clip. thermal and transducer overdrive protection

Trapezoidal, injection-malded, palypropylene with perforated steei grile,3*Handles
(left and right sides)

36mm standard pole-mount, suspended with integral M10 points,wedge monitor

680mm x 421mm x 382mm
26.8" x 16.6" x 15.0"

41.3 lbs /18.8 kg
